400 - 4500KW Steel Shredder Machine Eliminate Explosibility of
Metal Automatically
Working Principle
Scrap iron and steel raw materials shipped to feed incline through
the scales conveyor, feed incline mounted on two rotatable grinding
rollers, high and low , to flatten wins and into the crushing
chamber. In the crushing cavity composed of ten fixed on the
spindle between the disc and ten security branch of the disc is
free to swing the hammer, generated by high-speed rotation speed of
scrap metals smashing, torn, broken handle make scrap metal
processed into lumps or granules, through the lower part of the
grid and the top of the drop in the vibrating conveyor. Firstly it
failed to deal with a small enough scrap metal, and will again
handle the rotating disc and hammer until it can pass through the
grid so far.
Applications
The scrap steel shredder is designed to shred a wide variety of
light and thin material as discarded automobiles, tin plate,
household appliances, bicycles, empty cans, etc, making the
materials into pure charge for steel making. By smashing and
compressing, the shredder will remove the impurities, raise
density, lower transporting and smelting cost to offer good furnace
charge for steel plant.
Advantage
The large inertia, long life, fully enclosed rotating body
Using the heavy duty rotating body bearing.
Equipped with good impact resistance of the steel liner
Discharge grille with good to engage in impact performance
Features
1. Equipped with the large inertia, long life, fully enclosed
rotating body.
2. Using the heavy duty rotating body bearing.
3. The rotating body has lifting device, easy for staff close to
the equipment and safety maintenance.
4. Discharge grille with good to engage in impact performance.
5. Equipped with good impact resistance of the steel liner.
6. Equipped with the hydraulic opening of the upper device and
locking mechanisms for maintance staff easy to close to the middle
liner to safety repairs.
Technical Specifications
Model | Wide of feed opening(mm) | Power(KW/HP) | Capacity(t/h) |
PSX-400/450 | 1200 | 400KW/450KW/535HP | 6-10 |
PSX-750 | 2200 | 750(1000) | 15-20 |
PSX-900 | 2200 | 900(1200) | 20-30 |
PSX-1200 | 2500 | 1200(1600) | 25-40 |
PSX-1500 | 2500 | 1500(2000) | 40-50 |
PSX-2000 | 2500 | 2000 | 50-60 |
PSX-2250 | 2500 | 2250(3000) | 60-80 |
PSX-3000 | 2500 | 3000(4000) | 80-100 |
PSX-4500 | 2500 | 4500(6000) | 100-160 |
