Product Description
Y81 series metal hydraulic baler is capable of extruding various
metal leftover materials, steel parting, waste copper, aluminum,
copper, stainless steel and scraped car material into qualified
charging such as square column, cylinder, octagon body and other
shapes, in a bid to reduce transportation,refine costs and increase
transportation speed.
Features of the baler
1. Hydraulic drive, compact design, great sealing;
2. Customized press box size and bale size;
3. Bale discharging ways include turn-out, side-push out and
forward-out;
4. Designed with quick unit that can improve work efficiency
substantially;
5. Famous motor, hydraulic system, oil cylinder, piston pump,
electrical components;
6. Blades: our baler can compressing machinery scrap iron aluminum
metal baler with the knife, it can cut the long size material when
compressing, so it very goog for the long steel wire and big size
material.
Technical Parameters
| Model | Main Cyl.Force (ton) | Press Box Size
(mm) | Bale Section
(mm) | Bale Weight
(kg) | Power
(kw) |
| Y81F-125 | 125 | 1200*700*600 | 300*300 | 50-70 | 15 |
| Y81F-160 | 160 | 1600*1000*800 | 400*400 | 100-150 | 22 |
| Y81F-200 | 200 | 1800*1400*800 | 260/300(octagon) | 50-100 | 37/44 |
| Y81F-250 | 250 | 2000*1750*1000 | 500*500 | 250-450 | 60 |
| Y81F-250 | 250 | 2500*2000*1200 | 500*500/600*600 | 300-500 | 60 |
| Y81F-315 | 315 | 3000*2500*1200 | 600*600 | 400-700 | 90 |
| Y81F-315 | 315 | 3500*3000*1300 | 600*600/700*700 | 600-1000 | 90 |
Y81F-315
(double cyl.) | 315 | 4000*3000*1300 | 600*600/700*700 | 800-1200 | 90 |
| Y81F-400 | 400 | 3500*3000*1300 | 600*600/700*700 | 800-1300 | 135 |
| Y81K-400 | 400 | 4000*3000*1300 | 600*600/700*700 | 900-1300 | 135 |
| Y81F-500 | 500 | 3500*3000*1300 | 600*600/700*700 | 900-1500 | 135 |
Y81K-500
(double cyl.) | 500 | 3500/4000*3000*1300 | 600*600/700*700 | 900-1600 | 135 |
Y81K-630
(double cyl.) | 630 | 3500/4000*3000*1400 | 600*600/700*700 | 1100-1700 | 165 |
Y81K-800
(double cyl.) | 800 | 3500/4000*3000*1400 | 600*600/700*700 | 1200-1800 | 220 |
| Y81F-1000 | 1000 | 3500/4000*3000*1500 | 600*600/700*700 | 1300-1900 | 275 |
| Y81K-1500 | 1500 | 3500*3000*1500 | 700*700/800*800 | 1400-2100 | 330 |
Application
The materials include: steel shavings, scrap steel, scrap aluminum,
scrap copper, scrap stainless steel, scrap car scrap, etc.
Shipping
FAQ
Q1 : Can I add my logo on the machines?
A : Yes,OEM and ODM are available for us.
But you should send us the Trademark authorization letter.
Q2 : How can i get the after-service?
A : We will send you the spare parts by free if the problems caused by
us.
If it is the men-made problems, we also send the spare parts, but
you should pay.
Q3 : Do you have inspection procedures for machines?
A : 100% self-inspection before packing
Q4 : Can I have a visit to your factory before the order?
A : Sure, welcome to visit our factory.
Here is our factory address:No.29, Panlongshan Road, Jiangyin City,
Jiangsu Province, China.
Q5 : Can we order one set machine?
A : Yes, you can.
